MR-J3-10B

MR-J3-10B

Digital AC-Servo Amplifier MR-J3-B for Rated Motor Power up to 100 W

Category:

Description

Mitsubishi MR-J3-10B Series Servo Amplifier

Type:MELSERVO J3 Series Servo Amplifier
Rated capacity (kW):0.1
Output rated current (A):1.1
Voltage / Frequency:3-phase 200~230VAC 50/60Hz / 1-phase 200~230VAC 50/60Hz
Main circuit rated current (A):0.9
Interface power supply:24VDC ±10% (required current capacity: 0.15A
Width (mm):40
Height (mm):168
Depth (mm):135
Mass (kg):0.8



Catalog PDF

MR-J3 Servo Catalog
